How to Collect Azure Resource Data

The Azure collector is configured within the Fix Inventory Worker configuration via the config command in Fix Inventory Shell.

Prerequisites

This guide assumes that you have already installed Fix Inventory.

Directions

1. Enable the Azure Collector

1. Open the Fix Inventory Worker configuration via the config command in Fix Inventory Shell:

   > config edit fix.worker

2. Add azure to the list of collectors by modifying the configuration as follows:

   fixworker:
     ...
     # List of collectors to run
     collector:
       - 'azure'
       ...
   ...

2. Configure Azure

1. Open the Azure console.

2. In the search box, type App registrations and select the App registrations service:



3. Click New registration:



4. Enter a name for the application and click the Register button:



5. Make note of the displayed Application (client) ID and Directory (tenant) ID:



   note

   These values will be provided as client_id and tenant_id to the Azure collector.

6. Click on Certificates & secrets in the left-hand menu:



7. Click New client secret:



8. Enter a description for the secret, select an expiration period, and click the Add button:



9. Make note of the displayed Value of the created secret:



   note

   This value will be provided as client_secret to the Azure collector.

10. Click on API permissions in the left-hand menu:



11. Click Add a permission:



12. Click Azure Service Management:



13. Select the user_impersonation permission:



14. Click the Add permissions button:



15. In the search box, type Subscriptions and select the Subscriptions service:



16. Click on your subscription:



17. Click Access control (IAM) in the left-hand menu:



18. Click Add role assignment:



19. In the Role tab, select the Reader role:



20. Click the Next button:



21. In the Members tab, click Select members:



22. Search for the application you created earlier:



23. Click the application and click the Select button:



24. Click the Review + assign button:



3. Authenticate with Azure

Fix Inventory Worker Configuration

1. Open the Fix Inventory Worker configuration via the config command in Fix Inventory Shell:

   > config edit fix.worker

2. Modify the azure section of the configuration as follows, adding your API tokens and/or access keys:

   azure:
     accounts:
       default:
         client_secret:
           tenant_id: '<tenant ID>'
           client_id: '<client ID>'
           client_secret: '<client secret>'

Environment Variables

Instead of specifying API tokens or secret access keys in the Fix Inventory Worker configuration directly, it is possible to define them using the --override flag or FIXWORKER_OVERRIDE environment variable.

1. Set the FIXWORKER_OVERRIDE environment variable:

   • Add a environment variable definition to the fixworker service in docker-compose.yaml:

     docker-compose.yaml

     services:
       ...
       fixworker:
         environment:
           - FIXWORKER_OVERRIDE="azure.accounts.default.client_secret.tenant_id=<tenant ID> azure.accounts.default.client_secret.client_id=<client ID> azure.accounts.default.client_secret.client_secret=<client secret>"
       ...
     ...

   • Recreate the fixworker container with the updated service definition:

     $ docker-compose up -d
     note

     Docker Compose V2 integrated compose functions in to the Docker platform.

     In Docker Compose V2, the command is docker compose (no hyphen) instead of docker-compose.

4. Trigger Resource Collection

1. By default, Fix Inventory performs resource collection each hour. To immediately trigger a collect run, use the workflow run command in Fix Inventory Shell:

   > workflow run collect

2. Once the collect run completes, you can view a summary of collected Azure resources using the following search:

   > search is(azure_resource) | count kind
