config show Command

The config show command shows the specified configuration.

Usage

config show <id>

Parameters

Parameter	Description	Required?	Default Value
id	Configuration identifier	✔️

Examples

> configs show fix.core
​fixcore:
​  # API related properties.
​  api:
​    # TCP host(s) to bind on (default: ['localhost'])
​    web_hosts:
​      - 'localhost'
​    # TCP port to bind on (default: 8900)
​    web_port: 8900
​    # Web path root (default: /).
​    # This should only be required, if you are running a proxy server, that is not able to handle a sub-path.
​    web_path: '/'
​    # The url to the time series database. This path will be served under /tsdb/.
​    tsdb_proxy_url: null
​    # The directory where the UI is installed. This directory will be served under
​    ui_path: null
​    # The certificate configuration for this server.
​    host_certificate:
​      # The common name of the certificate
​      common_name: 'some.engineering'
​      # Include loopback in certificate
​      include_loopback: true
​      # List of DNS names to include in CSR
​      san_dns_names: []
​      # List of IP addresses to include in CSR
​      san_ip_addresses: []
​  # CLI related properties.
​  cli:
​    # Use this graph for CLI actions, if no graph is specified explicitly.
​    default_graph: 'fix'
​    # Use this graph section by default, if no section is specified.
​    # Relative paths will be interpreted with respect to this section.
​    default_section: 'reported'
​  # Properties for updating the graph.
​  graph_update:
​    # Max waiting time to complete a merge graph action.
​    merge_max_wait_time_seconds: 3600
​    # If a graph update takes longer than this duration, the update is aborted.
​    abort_after_seconds: 14401
​  # Runtime related properties.
​  runtime:
​    # Enable debug logging and exception tracing.
​    debug: false
​    # Log level (default: info)
​    log_level: 'info'
​    # PlantUML server URI for UML image rendering.
​    plantuml_server: 'http://plantuml.fixinventory.org:8080'
​    # Start the collect workflow, when the first handling actor connects to the system.
​    start_collect_on_subscriber_connect: false
​    # Help us improving Fix Inventory by collecting usage metrics.
​    # See https://fixinventory.org/docs/reference/telemetry for more information.
​    # This data is anonymous. No personally identifiable information is captured or stored.
​    usage_metrics: true
​  # Workflow related properties.
​  workflows:
​    collect_and_cleanup:
​      # Cron expression as schedule for the workflow to run.
​      schedule: '0 * * * *'
